Lift Trucks (Forklifts)
Lift Trucks (Forklifts)
REQUEST FOR QUOTE
| Specifications | |
|---|---|
| Manufacturer | Heli |
| Power Type | Diesel |
| Rated Capacity | 4000 kg |
| Load Center | 500 mm |
| Driving Mode | Seated |
| Dimentional Specifications | |
| Extended Mast Height – With Backrest, Unloaded (H2) | 4217 mm |
| Maximum Fork Height (H) | 3000 mm |
| Lowered Mast Height (H1) | 2275 mm |
| Free Lift | 150 mm |
| Backrest Height (From The Fork Height) (H13) | 1217 mm |
| Distance From The Seat Surface to The Overhead Guard (H6) | 980 mm |
| Overall Height (H4) | 2270 mm |
| Overall Length – With Fork (L) | 4145 mm |
| Overall Length – Without Fork (L’) | 3075 mm |
| Front Overhang (L2) | 555 mm |
| Rear Overhang (L3) | 520 mm |
| Wheel Base L1 | 2000 mm |
| Traction Pin Height (H9) | 385 mm |
| Minimum Under Clearance at Mast (H5) | 175 mm |
| Overall Width (W1) | 1480 mm |
| Maximum External Fork Distance (W5) | 1340 mm |
| Minimum External Fork Distance (W5) | 300 mm |
| Front Thread (W3) | 1180 mm |
| Rear Thread (W2) | 1190 mm |
| Minimum Turning Radius – Inside (r’) | 220 mm |
| Minimum Turning Radius – Outside (r) | 2720 mm |
| Minimum Right Angle Aisle Width (Ra) | 2480 mm |
| Mast Tilting Angle – Front (a) | 6 º |
| Mast Tilting Angle – Rear (ß) | 12 º |
| Fork Length (L4) | 1070 mm |
| Fork Width (W) | 150 mm |
| Fork Thickness (T) | 60 mm |
| Performance | |
| Maximum Travelling Speed with Load | 25 km/h |
| Maximum Travelling Speed without Load | 26 km/h |
| Lifting Speed with Load | 460 mm/s |
| Lifting Speed without Load | 520 mm/s |
| Lowering Speed with Load | < 600 mm/s |
| Lowering Speed without Load | > 300 mm/s |
| Traction Force – Loaded | 22 kN |
| Traction Force – Unloaded | 16 kN |
| Maximum Gradeability – Loaded | 18 % |
| Maximum Gradeability – Unloaded | 20 % |
| Weights | |
| Service Weight | 6500 kg |
| Weight Distribution Loaded – Front | 8925 kg |
| Weight Distribution Loaded – Rear | 1575 kg |
| Weight Distribution Unloaded – Front | 2700 kg |
| Weight Distribution Unloaded – Rear | 3800 kg |
| Tires | |
| Tire Number X=Driven Wheel (Front/Rear) | 2X/2 |
| Tire Type – Front | Pneumatic Tyre |
| Tire Type – Rear | Pneumatic Tyre |
| Tire Model – Front | 8.25-15-14PR |
| Tire Model – Rear | 7.00-12-12PR |
| Service Brake | Powered Brake Pedal Tyre |
| Parking Brake | Mechanical Hand Brake Lever Type |
| Drive Specifications | |
| Battery Voltage | 24 V |
| Battery Capacity | 80 Ah |
| Engine Model | Mitsubishi S6S-230 |
| Engine Rated Power | 52/2300 KW/rpm |
| Engine Rated Torque | 248/1700 Mn/rpm |
| Number of Engine Cylinders | 6 |
| Engine Cylinder Bore Size | 94 |
| Engine Stoke | 120 |
| Engine Displacement | 4.966 L |
| Engine Fuel Tank Capacity | 90 L |
| Number of Gears (Front/Rear) | 2-1 Power Shift |
REQUEST FOR QUOTE
| Specifications | |
|---|---|
| Manufacturer | Heli |
| Power Type | Diesel |
| Rated Capacity | 4500 kg |
| Load Center | 500 mm |
| Driving Mode | Seated |
| Dimentional Specifications | |
| Extended Mast Height – With Backrest, Unloaded (H2) | 4217 mm |
| Maximum Fork Height (H) | 3000 mm |
| Lowered Mast Height (H1) | 2275 mm |
| Free Lift | 150 mm |
| Backrest Height (From The Fork Height) (H13) | 1217 mm |
| Distance From The Seat Surface to The Overhead Guard (H6) | 980 mm |
| Overall Height (H4) | 2270 mm |
| Overall Length – With Fork (L) | 4165 mm |
| Overall Length – Without Fork (L’) | 3095 mm |
| Front Overhang (L2) | 555 mm |
| Rear Overhang (L3) | 540 mm |
| Wheel Base L1 | 2000 mm |
| Traction Pin Height (H9) | 385 mm |
| Minimum Under Clearance at Mast (H5) | 175 mm |
| Overall Width (W1) | 1480 mm |
| Maximum External Fork Distance (W5) | 1340 mm |
| Minimum External Fork Distance (W5) | 300 mm |
| Front Thread (W3) | 1180 mm |
| Rear Thread (W2) | 1190 mm |
| Minimum Turning Radius – Inside (r’) | 220 mm |
| Minimum Turning Radius – Outside (r) | 2740 mm |
| Minimum Right Angle Aisle Width (Ra) | 2500 mm |
| Mast Tilting Angle – Front (a) | 6 º |
| Mast Tilting Angle – Rear (ß) | 12 º |
| Fork Length (L4) | 1070 mm |
| Fork Width (W) | 150 mm |
| Fork Thickness (T) | 60 mm |
| Performance | |
| Maximum Travelling Speed with Load | 25 km/h |
| Maximum Travelling Speed without Load | 26 km/h |
| Lifting Speed with Load | 460 mm/s |
| Lifting Speed without Load | 520 mm/s |
| Lowering Speed with Load | < 600 mm/s |
| Lowering Speed without Load | > 300 mm/s |
| Traction Force – Loaded | 22 kN |
| Traction Force – Unloaded | 16 kN |
| Maximum Gradeability – Loaded | 17 % |
| Maximum Gradeability – Unloaded | 20 % |
| Weights | |
| Service Weight | 6800 kg |
| Weight Distribution Loaded – Front | 9750 kg |
| Weight Distribution Loaded – Rear | 1550 kg |
| Weight Distribution Unloaded – Front | 2710 kg |
| Weight Distribution Unloaded – Rear | 4090 kg |
| Tires | |
| Tire Number X=Driven Wheel (Front/Rear) | 2X/2 |
| Tire Type – Front | Pneumatic Tyre |
| Tire Type – Rear | Pneumatic Tyre |
| Tire Model – Front | 300-15-20PR |
| Tire Model – Rear | 7.00-12-12PR |
| Service Brake | Powered Brake Pedal Tyre |
| Parking Brake | Mechanical Hand Brake Lever Type |
| Drive Specifications | |
| Battery Voltage | 24 V |
| Battery Capacity | 80 Ah |
| Engine Model | Mitsubishi S6S-230 |
| Engine Rated Power | 52/2300 KW/rpm |
| Engine Rated Torque | 248/1700 Mn/rpm |
| Number of Engine Cylinders | 6 |
| Engine Cylinder Bore Size | 94 |
| Engine Stoke | 120 |
| Engine Displacement | 4.966 L |
| Engine Fuel Tank Capacity | 90 L |
| Number of Gears (Front/Rear) | 2-1 Power Shift |
REQUEST FOR QUOTE
| Specifications | |
|---|---|
| Manufacturer | Heli |
| Power Type | Diesel |
| Rated Capacity | 5000 kg |
| Load Center | 500 mm |
| Driving Mode | Seated |
| Dimentional Specifications | |
| Extended Mast Height – With Backrest, Unloaded (H2) | 4217 mm |
| Maximum Fork Height (H) | 3000 mm |
| Lowered Mast Height (H1) | 2275 mm |
| Free Lift | 150 mm |
| Backrest Height (From The Fork Height) (H13) | 1217 mm |
| Distance From The Seat Surface to The Overhead Guard (H6) | 980 mm |
| Overall Height (H4) | 2270 mm |
| Overall Length – With Fork (L) | 4209 mm |
| Overall Length – Without Fork (L’) | 3139 mm |
| Front Overhang (L2) | 555 mm |
| Rear Overhang (L3) | 584 mm |
| Wheel Base L1 | 2000 mm |
| Traction Pin Height (H9) | 385 mm |
| Minimum Under Clearance at Mast (H5) | 175 mm |
| Overall Width (W1) | 1480 mm |
| Maximum External Fork Distance (W5) | 1340 mm |
| Minimum External Fork Distance (W5) | 300 mm |
| Front Thread (W3) | 1180 mm |
| Rear Thread (W2) | 1190 mm |
| Minimum Turning Radius – Inside (r’) | 220 mm |
| Minimum Turning Radius – Outside (r) | 2800 mm |
| Minimum Right Angle Aisle Width (Ra) | 2550 mm |
| Mast Tilting Angle – Front (a) | 6 º |
| Mast Tilting Angle – Rear (ß) | 12 º |
| Fork Length (L4) | 1070 mm |
| Fork Width (W) | 150 mm |
| Fork Thickness (T) | 60 mm |
| Performance | |
| Maximum Travelling Speed with Load | 25 km/h |
| Maximum Travelling Speed without Load | 26 km/h |
| Lifting Speed with Load | 460 mm/s |
| Lifting Speed without Load | 520 mm/s |
| Lowering Speed with Load | < 600 mm/s |
| Lowering Speed without Load | > 300 mm/s |
| Traction Force – Loaded | 22 kN |
| Traction Force – Unloaded | 16 kN |
| Maximum Gradeability – Loaded | 16 % |
| Maximum Gradeability – Unloaded | 20 % |
| Weights | |
| Service Weight | 7100 kg |
| Weight Distribution Loaded – Front | 10500 kg |
| Weight Distribution Loaded – Rear | 1600 kg |
| Weight Distribution Unloaded – Front | 2680 kg |
| Weight Distribution Unloaded – Rear | 4420 kg |
| Tires | |
| Tire Number X=Driven Wheel (Front/Rear) | 2X/2 |
| Tire Type – Front | Pneumatic Tyre |
| Tire Type – Rear | Pneumatic Tyre |
| Tire Model – Front | 300-15-20PR |
| Tire Model – Rear | 7.00-12-12PR |
| Service Brake | Powered Brake Pedal Tyre |
| Parking Brake | Mechanical Hand Brake Lever Type |
| Drive Specifications | |
| Battery Voltage | 24 V |
| Battery Capacity | 80 Ah |
| Engine Model | Mitsubishi S6S-230 |
| Engine Rated Power | 52/2300 KW/rpm |
| Engine Rated Torque | 248/1700 Mn/rpm |
| Number of Engine Cylinders | 6 |
| Engine Cylinder Bore Size | 94 |
| Engine Stoke | 120 |
| Engine Displacement | 4.966 L |
| Engine Fuel Tank Capacity | 90 L |
| Number of Gears (Front/Rear) | 2-1 Power Shift |
REQUEST FOR QUOTE
| Specifications | |
|---|---|
| Manufacturer | Heli |
| Power Type | Gasoline/LPG |
| Rated Capacity | 4000 kg |
| Load Center | 500 mm |
| Driving Mode | Seated |
| Dimentional Specifications | |
| Extended Mast Height – With Backrest, Unloaded (H2) | 4217 mm |
| Maximum Fork Height (H) | 3000 mm |
| Lowered Mast Height (H1) | 2275 mm |
| Free Lift | 150 mm |
| Backrest Height (From The Fork Height) (H13) | 1217 mm |
| Distance From The Seat Surface to The Overhead Guard (H6) | 980 mm |
| Overall Height (H4) | 2270 mm |
| Overall Length – With Fork (L) | 4145 mm |
| Overall Length – Without Fork (L’) | 3075 mm |
| Front Overhang (L2) | 555 mm |
| Rear Overhang (L3) | 520 mm |
| Wheel Base L1 | 2000 mm |
| Traction Pin Height (H9) | 385 mm |
| Minimum Under Clearance at Mast (H5) | 175 mm |
| Overall Width (W1) | 1480 mm |
| Maximum External Fork Distance (W5) | 1340 mm |
| Minimum External Fork Distance (W5) | 300 mm |
| Front Thread (W3) | 1180 mm |
| Rear Thread (W2) | 1190 mm |
| Minimum Turning Radius – Inside (r’) | 220 mm |
| Minimum Turning Radius – Outside (r) | 2720 mm |
| Minimum Right Angle Aisle Width (Ra) | 2480 mm |
| Mast Tilting Angle – Front (a) | 6 º |
| Mast Tilting Angle – Rear (ß) | 12 º |
| Fork Length (L4) | 1070 mm |
| Fork Width (W) | 150 mm |
| Fork Thickness (T) | 60 mm |
| Performance | |
| Maximum Travelling Speed with Load | 25 km/h |
| Maximum Travelling Speed without Load | 26 km/h |
| Lifting Speed with Load | 460 mm/s |
| Lifting Speed without Load | 520 mm/s |
| Lowering Speed with Load | < 600 mm/s |
| Lowering Speed without Load | > 300 mm/s |
| Traction Force – Loaded | 25 kN |
| Traction Force – Unloaded | 16 kN |
| Maximum Gradeability – Loaded | 18 % |
| Maximum Gradeability – Unloaded | 20 % |
| Weights | |
| Service Weight | 6500 kg |
| Weight Distribution Loaded – Front | 8925 kg |
| Weight Distribution Loaded – Rear | 1575 kg |
| Weight Distribution Unloaded – Front | 2700 kg |
| Weight Distribution Unloaded – Rear | 3800 kg |
| Tires | |
| Tire Number X=Driven Wheel (Front/Rear) | 2X/2 |
| Tire Type – Front | Pneumatic Tyre |
| Tire Type – Rear | Pneumatic Tyre |
| Tire Model – Front | 8.25-15-14PR |
| Tire Model – Rear | 7.00-12-12PR |
| Service Brake | Powered Brake Pedal Tyre |
| Parking Brake | Mechanical Hand Brake Lever Type |
| Drive Specifications | |
| Battery Voltage | 12 V |
| Battery Capacity | 100 Ah |
| Engine Model | GM 4.3L Gasoline/LPG |
| Engine Rated Power – Gasoline | 70/2300 KW/rpm |
| Engine Rated Power – LPG | 76.6/2300 KW/rpm |
| Engine Rated Torque – Gasoline | 287/1700 Mn/rpm |
| Engine Rated Torque – LPG | 323.5/1700 Mn/rpm |
| Number of Engine Cylinders | 6 |
| Engine Cylinder Bore Size | 101.6 |
| Engine Stoke | 88.39 |
| Engine Displacement | 4.29418 L |
| Engine Fuel Tank Capacity | 90 L |
| Number of Gears (Front/Rear) | 2-1 Power Shift |
REQUEST FOR QUOTE
| Specifications | |
|---|---|
| Manufacturer | Heli |
| Power Type | Gasoline/LPG |
| Rated Capacity | 4500 kg |
| Load Center | 500 mm |
| Driving Mode | Seated |
| Dimentional Specifications | |
| Extended Mast Height – With Backrest, Unloaded (H2) | 4217 mm |
| Maximum Fork Height (H) | 3000 mm |
| Lowered Mast Height (H1) | 2275 mm |
| Free Lift | 150 mm |
| Backrest Height (From The Fork Height) (H13) | 1217 mm |
| Distance From The Seat Surface to The Overhead Guard (H6) | 980 mm |
| Overall Height (H4) | 2270 mm |
| Overall Length – With Fork (L) | 4165 mm |
| Overall Length – Without Fork (L’) | 3095 mm |
| Front Overhang (L2) | 555 mm |
| Rear Overhang (L3) | 540 mm |
| Wheel Base L1 | 2000 mm |
| Traction Pin Height (H9) | 385 mm |
| Minimum Under Clearance at Mast (H5) | 175 mm |
| Overall Width (W1) | 1480 mm |
| Maximum External Fork Distance (W5) | 1340 mm |
| Minimum External Fork Distance (W5) | 300 mm |
| Front Thread (W3) | 1180 mm |
| Rear Thread (W2) | 1190 mm |
| Minimum Turning Radius – Inside (r’) | 220 mm |
| Minimum Turning Radius – Outside (r) | 2740 mm |
| Minimum Right Angle Aisle Width (Ra) | 2500 mm |
| Mast Tilting Angle – Front (a) | 6 º |
| Mast Tilting Angle – Rear (ß) | 12 º |
| Fork Length (L4) | 1070 mm |
| Fork Width (W) | 150 mm |
| Fork Thickness (T) | 60 mm |
| Performance | |
| Maximum Travelling Speed with Load | 25 km/h |
| Maximum Travelling Speed without Load | 26 km/h |
| Lifting Speed with Load | 460 mm/s |
| Lifting Speed without Load | 520 mm/s |
| Lowering Speed with Load | < 600 mm/s |
| Lowering Speed without Load | > 300 mm/s |
| Traction Force – Loaded | 25 kN |
| Traction Force – Unloaded | 16 kN |
| Maximum Gradeability – Loaded | 17 % |
| Maximum Gradeability – Unloaded | 20 % |
| Weights | |
| Service Weight | 6800 kg |
| Weight Distribution Loaded – Front | 9750 kg |
| Weight Distribution Loaded – Rear | 1550 kg |
| Weight Distribution Unloaded – Front | 2710 kg |
| Weight Distribution Unloaded – Rear | 4090 kg |
| Tires | |
| Tire Number X=Driven Wheel (Front/Rear) | 2X/2 |
| Tire Type – Front | Pneumatic Tyre |
| Tire Type – Rear | Pneumatic Tyre |
| Tire Model – Front | 300-15-20PR |
| Tire Model – Rear | 7.00-12-12PR |
| Service Brake | Powered Brake Pedal Tyre |
| Parking Brake | Mechanical Hand Brake Lever Type |
| Drive Specifications | |
| Battery Voltage | 12 V |
| Battery Capacity | 100 Ah |
| Engine Model | GM 4.3L Gasoline/LPG |
| Engine Rated Power – Gasoline | 70/2300 KW/rpm |
| Engine Rated Power – LPG | 76.6/2300 KW/rpm |
| Engine Rated Torque – Gasoline | 287/1700 Mn/rpm |
| Engine Rated Torque – LPG | 323.5/1700 Mn/rpm |
| Number of Engine Cylinders | 6 |
| Engine Cylinder Bore Size | 101.6 |
| Engine Stoke | 88.39 |
| Engine Displacement | 4.29418 L |
| Engine Fuel Tank Capacity | 90 L |
| Number of Gears (Front/Rear) | 2-1 Power Shift |
REQUEST FOR QUOTE
| Specifications | |
|---|---|
| Manufacturer | Heli |
| Power Type | Gasoline/LPG |
| Rated Capacity | 5000 kg |
| Load Center | 500 mm |
| Driving Mode | Seated |
| Dimentional Specifications | |
| Extended Mast Height – With Backrest, Unloaded (H2) | 4217 mm |
| Maximum Fork Height (H) | 3000 mm |
| Lowered Mast Height (H1) | 2275 mm |
| Free Lift | 150 mm |
| Backrest Height (From The Fork Height) (H13) | 1217 mm |
| Distance From The Seat Surface to The Overhead Guard (H6) | 980 mm |
| Overall Height (H4) | 2270 mm |
| Overall Length – With Fork (L) | 4209 mm |
| Overall Length – Without Fork (L’) | 3139 mm |
| Front Overhang (L2) | 555 mm |
| Rear Overhang (L3) | 584 mm |
| Wheel Base L1 | 2000 mm |
| Traction Pin Height (H9) | 385 mm |
| Minimum Under Clearance at Mast (H5) | 175 mm |
| Overall Width (W1) | 1480 mm |
| Maximum External Fork Distance (W5) | 1340 mm |
| Minimum External Fork Distance (W5) | 300 mm |
| Front Thread (W3) | 1180 mm |
| Rear Thread (W2) | 1190 mm |
| Minimum Turning Radius – Inside (r’) | 220 mm |
| Minimum Turning Radius – Outside (r) | 2800 mm |
| Minimum Right Angle Aisle Width (Ra) | 2550 mm |
| Mast Tilting Angle – Front (a) | 6 º |
| Mast Tilting Angle – Rear (ß) | 12 º |
| Fork Length (L4) | 1070 mm |
| Fork Width (W) | 150 mm |
| Fork Thickness (T) | 60 mm |
| Performance | |
| Maximum Travelling Speed with Load | 25 km/h |
| Maximum Travelling Speed without Load | 26 km/h |
| Lifting Speed with Load | 460 mm/s |
| Lifting Speed without Load | 520 mm/s |
| Lowering Speed with Load | < 600 mm/s |
| Lowering Speed without Load | > 300 mm/s |
| Traction Force – Loaded | 25 kN |
| Traction Force – Unloaded | 16 kN |
| Maximum Gradeability – Loaded | 16 % |
| Maximum Gradeability – Unloaded | 20 % |
| Weights | |
| Service Weight | 7100 kg |
| Weight Distribution Loaded – Front | 10500 kg |
| Weight Distribution Loaded – Rear | 1600 kg |
| Weight Distribution Unloaded – Front | 2680 kg |
| Weight Distribution Unloaded – Rear | 4420 kg |
| Tires | |
| Tire Number X=Driven Wheel (Front/Rear) | 2X/2 |
| Tire Type – Front | Pneumatic Tyre |
| Tire Type – Rear | Pneumatic Tyre |
| Tire Model – Front | 300-15-20PR |
| Tire Model – Rear | 7.00-12-12PR |
| Service Brake | Powered Brake Pedal Tyre |
| Parking Brake | Mechanical Hand Brake Lever Type |
| Drive Specifications | |
| Battery Voltage | 12 V |
| Battery Capacity | 100 Ah |
| Engine Model | GM 4.3L Gasoline/LPG |
| Engine Rated Power – Gasoline | 70/2300 KW/rpm |
| Engine Rated Power – LPG | 76.6/2300 KW/rpm |
| Engine Rated Torque – Gasoline | 287/1700 Mn/rpm |
| Engine Rated Torque – LPG | 323.5/1700 Mn/rpm |
| Number of Engine Cylinders | 6 |
| Engine Cylinder Bore Size | 101.6 |
| Engine Stoke | 88.39 |
| Engine Displacement | 4.29418 L |
| Engine Fuel Tank Capacity | 90 L |
| Number of Gears (Front/Rear) | 2-1 Power Shift |
REQUEST FOR QUOTE
| Specifications | |
|---|---|
| Manufacturer | Heli |
| Power Type | Diesel |
| Rated Capacity | 4000 kg |
| Load Center | 500 mm |
| Driving Mode | Seated |
| Dimentional Specifications | |
| Extended Mast Height – With Backrest, Unloaded (H2) | 4217 mm |
| Maximum Fork Height (H) | 3000 mm |
| Lowered Mast Height (H1) | 2275 mm |
| Free Lift | 150 mm |
| Backrest Height (From The Fork Height) (H13) | 1217 mm |
| Distance From The Seat Surface to The Overhead Guard (H6) | 980 mm |
| Overall Height (H4) | 2270 mm |
| Overall Length – With Fork (L) | 4145 mm |
| Overall Length – Without Fork (L’) | 3075 mm |
| Front Overhang (L2) | 555 mm |
| Rear Overhang (L3) | 520 mm |
| Wheel Base L1 | 2000 mm |
| Traction Pin Height (H9) | 385 mm |
| Minimum Under Clearance at Mast (H5) | 175 mm |
| Overall Width (W1) | 1480 mm |
| Maximum External Fork Distance (W5) | 1340 mm |
| Minimum External Fork Distance (W5) | 300 mm |
| Front Thread (W3) | 1180 mm |
| Rear Thread (W2) | 1190 mm |
| Minimum Turning Radius – Inside (r’) | 220 mm |
| Minimum Turning Radius – Outside (r) | 2720 mm |
| Minimum Right Angle Aisle Width (Ra) | 2480 mm |
| Mast Tilting Angle – Front (a) | 6 º |
| Mast Tilting Angle – Rear (ß) | 12 º |
| Fork Length (L4) | 1070 mm |
| Fork Width (W) | 150 mm |
| Fork Thickness (T) | 60 mm |
| Performance | |
| Maximum Travelling Speed with Load | 18 km/h |
| Maximum Travelling Speed without Load | 19 km/h |
| Lifting Speed with Load | 360 mm/s |
| Lifting Speed without Load | 390 mm/s |
| Lowering Speed with Load | < 600 mm/s |
| Lowering Speed without Load | > 300 mm/s |
| Traction Force – Loaded | 21 kN |
| Traction Force – Unloaded | 14 kN |
| Maximum Gradeability – Loaded | 17 % |
| Maximum Gradeability – Unloaded | 20 % |
| Weights | |
| Service Weight | 6200 kg |
| Weight Distribution Loaded – Front | 8568 kg |
| Weight Distribution Loaded – Rear | 1632 kg |
| Weight Distribution Unloaded – Front | 2635 kg |
| Weight Distribution Unloaded – Rear | 3565 kg |
| Tires | |
| Tire Number X=Driven Wheel (Front/Rear) | 2X/2 |
| Tire Type – Front | Pneumatic Tyre |
| Tire Type – Rear | Pneumatic Tyre |
| Tire Model – Front | 8.25-15-14PR |
| Tire Model – Rear | 7.00-12-12PR |
| Service Brake | Vacuum Assist – Pedal Type |
| Parking Brake | Mechanical Hand Brake Lever Type |
| Drive Specifications | |
| Battery Voltage | 24 V |
| Battery Capacity | 80 Ah |
| Engine Model | Xinchang 4D35G |
| Engine Rated Power | 48/2300 KW/rpm |
| Engine Rated Torque | 230/1600-1800 Mn/rpm |
| Number of Engine Cylinders | 4 |
| Engine Cylinder Bore Size | 98 |
| Engine Stoke | 115 |
| Engine Displacement | 3.5 L |
| Engine Fuel Tank Capacity | 90 L |
| Number of Gears (Front/Rear) | 2-2 Manual Shift |
REQUEST FOR QUOTE
| Specifications | |
|---|---|
| Manufacturer | Heli |
| Power Type | Diesel |
| Rated Capacity | 4500 kg |
| Load Center | 500 mm |
| Driving Mode | Seated |
| Dimentional Specifications | |
| Extended Mast Height – With Backrest, Unloaded (H2) | 4217 mm |
| Maximum Fork Height (H) | 3000 mm |
| Lowered Mast Height (H1) | 2275 mm |
| Free Lift | 150 mm |
| Backrest Height (From The Fork Height) (H13) | 1217 mm |
| Distance From The Seat Surface to The Overhead Guard (H6) | 980 mm |
| Overall Height (H4) | 2270 mm |
| Overall Length – With Fork (L) | 4165 mm |
| Overall Length – Without Fork (L’) | 3095 mm |
| Front Overhang (L2) | 555 mm |
| Rear Overhang (L3) | 540 mm |
| Wheel Base L1 | 2000 mm |
| Traction Pin Height (H9) | 385 mm |
| Minimum Under Clearance at Mast (H5) | 175 mm |
| Overall Width (W1) | 1480 mm |
| Maximum External Fork Distance (W5) | 1340 mm |
| Minimum External Fork Distance (W5) | 300 mm |
| Front Thread (W3) | 1180 mm |
| Rear Thread (W2) | 1190 mm |
| Minimum Turning Radius – Inside (r’) | 220 mm |
| Minimum Turning Radius – Outside (r) | 2740 mm |
| Minimum Right Angle Aisle Width (Ra) | 2500 mm |
| Mast Tilting Angle – Front (a) | 6 º |
| Mast Tilting Angle – Rear (ß) | 12 º |
| Fork Length (L4) | 1070 mm |
| Fork Width (W) | 150 mm |
| Fork Thickness (T) | 60 mm |
| Performance | |
| Maximum Travelling Speed with Load | 18 km/h |
| Maximum Travelling Speed without Load | 19 km/h |
| Lifting Speed with Load | 360 mm/s |
| Lifting Speed without Load | 390 mm/s |
| Lowering Speed with Load | < 600 mm/s |
| Lowering Speed without Load | > 300 mm/s |
| Traction Force – Loaded | 21 kN |
| Traction Force – Unloaded | 14 kN |
| Maximum Gradeability – Loaded | 16 % |
| Maximum Gradeability – Unloaded | 20 % |
| Weights | |
| Service Weight | 6500 kg |
| Weight Distribution Loaded – Front | 9320 kg |
| Weight Distribution Loaded – Rear | 1680 kg |
| Weight Distribution Unloaded – Front | 2730 kg |
| Weight Distribution Unloaded – Rear | 3770 kg |
| Tires | |
| Tire Number X=Driven Wheel (Front/Rear) | 2X/2 |
| Tire Type – Front | Pneumatic Tyre |
| Tire Type – Rear | Pneumatic Tyre |
| Tire Model – Front | 8.25-15-14PR |
| Tire Model – Rear | 7.00-12-12PR |
| Service Brake | Vacuum Assist – Pedal Type |
| Parking Brake | Mechanical Hand Brake Lever Type |
| Drive Specifications | |
| Battery Voltage | 24 V |
| Battery Capacity | 80 Ah |
| Engine Model | Xinchang 4D35G |
| Engine Rated Power | 48/2301 KW/rpm |
| Engine Rated Torque | 230/1600-1801 Mn/rpm |
| Number of Engine Cylinders | 4 |
| Engine Cylinder Bore Size | 98 |
| Engine Stoke | 115 |
| Engine Displacement | 3.5 L |
| Engine Fuel Tank Capacity | 90 L |
| Number of Gears (Front/Rear) | 2-2 Manual Shift |
REQUEST FOR QUOTE
| Specifications | |
|---|---|
| Manufacturer | Heli |
| Power Type | Diesel |
| Rated Capacity | 5000 kg |
| Load Center | 500 mm |
| Driving Mode | Seated |
| Dimentional Specifications | |
| Extended Mast Height – With Backrest, Unloaded (H2) | 4217 mm |
| Maximum Fork Height (H) | 3000 mm |
| Lowered Mast Height (H1) | 2275 mm |
| Free Lift | 150 mm |
| Backrest Height (From The Fork Height) (H13) | 1217 mm |
| Distance From The Seat Surface to The Overhead Guard (H6) | 980 mm |
| Overall Height (H4) | 2270 mm |
| Overall Length – With Fork (L) | 4209 mm |
| Overall Length – Without Fork (L’) | 3139 mm |
| Front Overhang (L2) | 555 mm |
| Rear Overhang (L3) | 584 mm |
| Wheel Base L1 | 2000 mm |
| Traction Pin Height (H9) | 385 mm |
| Minimum Under Clearance at Mast (H5) | 175 mm |
| Overall Width (W1) | 1480 mm |
| Maximum External Fork Distance (W5) | 1340 mm |
| Minimum External Fork Distance (W5) | 300 mm |
| Front Thread (W3) | 1180 mm |
| Rear Thread (W2) | 1190 mm |
| Minimum Turning Radius – Inside (r’) | 220 mm |
| Minimum Turning Radius – Outside (r) | 2800 mm |
| Minimum Right Angle Aisle Width (Ra) | 2550 mm |
| Mast Tilting Angle – Front (a) | 6 º |
| Mast Tilting Angle – Rear (ß) | 12 º |
| Fork Length (L4) | 1070 mm |
| Fork Width (W) | 150 mm |
| Fork Thickness (T) | 60 mm |
| Performance | |
| Maximum Travelling Speed with Load | 18 km/h |
| Maximum Travelling Speed without Load | 19 km/h |
| Lifting Speed with Load | 360 mm/s |
| Lifting Speed without Load | 390 mm/s |
| Lowering Speed with Load | < 600 mm/s |
| Lowering Speed without Load | > 300 mm/s |
| Traction Force – Loaded | 31 kN |
| Traction Force – Unloaded | 14 kN |
| Maximum Gradeability – Loaded | 20 % |
| Maximum Gradeability – Unloaded | 25 % |
| Weights | |
| Service Weight | 6800 kg |
| Weight Distribution Loaded – Front | 10030 kg |
| Weight Distribution Loaded – Rear | 1770 kg |
| Weight Distribution Unloaded – Front | 2890 kg |
| Weight Distribution Unloaded – Rear | 3910 kg |
| Tires | |
| Tire Number X=Driven Wheel (Front/Rear) | 2X/2 |
| Tire Type – Front | Pneumatic Tyre |
| Tire Type – Rear | Pneumatic Tyre |
| Tire Model – Front | 300-15-20PR |
| Tire Model – Rear | 7.00-12-12PR |
| Service Brake | Vacuum Assist – Pedal Type |
| Parking Brake | Mechanical Hand Brake Lever Type |
| Drive Specifications | |
| Battery Voltage | 24 V |
| Battery Capacity | 80 Ah |
| Engine Model | Wuxi CA4110 |
| Engine Rated Power | 61/2200 KW/rpm |
| Engine Rated Torque | 305/1400-1600 Mn/rpm |
| Number of Engine Cylinders | 4 |
| Engine Cylinder Bore Size | 110 |
| Engine Stoke | 125 |
| Engine Displacement | 4.752 L |
| Engine Fuel Tank Capacity | 90 L |
| Number of Gears (Front/Rear) | 2-2 Manual Shift |
Lift Trucks (Forklifts)
REQUEST FOR QUOTE
Specifications
Manufacturer
Heli
Power Type
Diesel
Rated Capacity
4000 kg
Load Center
500 mm
Driving Mode
Seated
Dimentional Specifications
Extended Mast Height – With Backrest, Unloaded (H2)
4217 mm
Maximum Fork Height (H)
3000 mm
Lowered Mast Height (H1)
2275 mm
Free Lift
150 mm
Backrest Height (From The Fork Height) (H13)
1217 mm
Distance From The Seat Surface to The Overhead Guard (H6)
980 mm
Overall Height (H4)
2270 mm
Overall Lengt
Read More
REQUEST FOR QUOTE
Specifications
Manufacturer
Heli
Power Type
Diesel
Rated Capacity
4500 kg
Load Center
500 mm
Driving Mode
Seated
Dimentional Specifications
Extended Mast Height – With Backrest, Unloaded (H2)
4217 mm
Maximum Fork Height (H)
3000 mm
Lowered Mast Height (H1)
2275 mm
Free Lift
150 mm
Backrest Height (From The Fork Height) (H13)
1217 mm
Distance From The Seat Surface to The Overhead Guard (H6)
980 mm
Overall Height (H4)
2270 mm
Overall L
Read More
REQUEST FOR QUOTE
Specifications
Manufacturer
Heli
Power Type
Diesel
Rated Capacity
5000 kg
Load Center
500 mm
Driving Mode
Seated
Dimentional Specifications
Extended Mast Height – With Backrest, Unloaded (H2)
4217 mm
Maximum Fork Height (H)
3000 mm
Lowered Mast Height (H1)
2275 mm
Free Lift
150 mm
Backrest Height (From The Fork Height) (H13)
1217 mm
Distance From The Seat Surface to The Overhead Guard (H6)
980 mm
Overall Height (H4)
2270 mm
Overall L
Read More
REQUEST FOR QUOTE
Specifications
Manufacturer
Heli
Power Type
Gasoline/LPG
Rated Capacity
4000 kg
Load Center
500 mm
Driving Mode
Seated
Dimentional Specifications
Extended Mast Height – With Backrest, Unloaded (H2)
4217 mm
Maximum Fork Height (H)
3000 mm
Lowered Mast Height (H1)
2275 mm
Free Lift
150 mm
Backrest Height (From The Fork Height) (H13)
1217 mm
Distance From The Seat Surface to The Overhead Guard (H6)
980 mm
Overall Height (H4)
2270 mm
Ove
Read More
REQUEST FOR QUOTE
Specifications
Manufacturer
Heli
Power Type
Gasoline/LPG
Rated Capacity
4500 kg
Load Center
500 mm
Driving Mode
Seated
Dimentional Specifications
Extended Mast Height – With Backrest, Unloaded (H2)
4217 mm
Maximum Fork Height (H)
3000 mm
Lowered Mast Height (H1)
2275 mm
Free Lift
150 mm
Backrest Height (From The Fork Height) (H13)
1217 mm
Distance From The Seat Surface to The Overhead Guard (H6)
980 mm
Overall Height (H4)
2270 mm
Ove
Read More
REQUEST FOR QUOTE
Specifications
Manufacturer
Heli
Power Type
Gasoline/LPG
Rated Capacity
5000 kg
Load Center
500 mm
Driving Mode
Seated
Dimentional Specifications
Extended Mast Height – With Backrest, Unloaded (H2)
4217 mm
Maximum Fork Height (H)
3000 mm
Lowered Mast Height (H1)
2275 mm
Free Lift
150 mm
Backrest Height (From The Fork Height) (H13)
1217 mm
Distance From The Seat Surface to The Overhead Guard (H6)
980 mm
Overall Height (H4)
2270 mm
Ove
Read More
REQUEST FOR QUOTE
Specifications
Manufacturer
Heli
Power Type
Diesel
Rated Capacity
4000 kg
Load Center
500 mm
Driving Mode
Seated
Dimentional Specifications
Extended Mast Height – With Backrest, Unloaded (H2)
4217 mm
Maximum Fork Height (H)
3000 mm
Lowered Mast Height (H1)
2275 mm
Free Lift
150 mm
Backrest Height (From The Fork Height) (H13)
1217 mm
Distance From The Seat Surface to The Overhead Guard (H6)
980 mm
Overall Height (H4)
2270 mm
Overall L
Read More
REQUEST FOR QUOTE
Specifications
Manufacturer
Heli
Power Type
Diesel
Rated Capacity
4500 kg
Load Center
500 mm
Driving Mode
Seated
Dimentional Specifications
Extended Mast Height – With Backrest, Unloaded (H2)
4217 mm
Maximum Fork Height (H)
3000 mm
Lowered Mast Height (H1)
2275 mm
Free Lift
150 mm
Backrest Height (From The Fork Height) (H13)
1217 mm
Distance From The Seat Surface to The Overhead Guard (H6)
980 mm
Overall Height (H4)
2270 mm
Overall L
Read More
REQUEST FOR QUOTE
Specifications
Manufacturer
Heli
Power Type
Diesel
Rated Capacity
5000 kg
Load Center
500 mm
Driving Mode
Seated
Dimentional Specifications
Extended Mast Height – With Backrest, Unloaded (H2)
4217 mm
Maximum Fork Height (H)
3000 mm
Lowered Mast Height (H1)
2275 mm
Free Lift
150 mm
Backrest Height (From The Fork Height) (H13)
1217 mm
Distance From The Seat Surface to The Overhead Guard (H6)
980 mm
Overall Height (H4)
2270 mm
Overall L
Read More
